Standard configuration
HFC R404a environmental friendly refrigerant;
Multi-function operating panel and uP controller;
Ultra-thin evaporator;
Hot gas defrosting system;
DC12V/24V operating voltage;
HFC134a or 452a refrigerant options may be available per prior agreement.
Safety devices
- Input or output H and L voltage protection;
- Thermal protection;
- System HP/LP cutout switch;
- Liquid injection and oil return protection devices;
- Wire harness ESD insulation methods which improve system protection from electromagnetic interference;
- Vehicle battery protection device.
Operation and control component
-
Microprocessor control system; -
Automatic / manual defrost; -
Digital display -
Fahrenheit or Celsius display for set point temperature and return air temperature, parameters setting alarm codes.
Product key features
01
Suitable for all electric vans;
02
Save fuel consumption, environmentally-friendly;
03
Integrated design, compressor and electrical parts are all located in condenser;
04
Special battery unit protection, avoids large impulse current;
05
Suitable for high DC voltage:DC200-700V;
06
Constant cooling capacity, not affected by vehicle speed;
07
Evaporator copper tubes with aluminum fins, fast cooling, large airflow;
08
Optional:Heating, electric stand-by function and CAN telecommunications.
Specifications
|
Model |
Refrigerant |
Cooling Capacity(W) |
Evaporator Airflow |
Application (m3) |
Evaporator |
Condenser |
|||
|
Dimension |
Weight(Kg) |
Dimension |
Weight(Kg) |
||||||
|
0℃/+30℃ |
-18℃/+30℃ |
||||||||
|
KX-200ER |
R404a |
2250 |
1260 |
1000 |
4~7 |
725*560*170 |
12 |
1150*850*240 |
60 |
Note:
Application-internal volume is for reference only, it depends on insulation material (K factor should be equal or lower than 0.32Watts/m²℃), ambient temperature, precooling, load and type of goods etc.
